Usage:Used for low pressure liquid delivery, such as water, gas, and oil. Oil drilling and machinery manufacturing, etc.

ERW: Electric Resistance Welded pipe

HFI: High Frequency Induction weld pipe

EFW: Electric Fusion Welded Pipe

Standard: API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, JIS G3452, BS1387

Certificate: API 5L PSL1/ PSL2, API 5CT

Out Diameter: 21.3mm – 610mm

Wall Thickness:1.8 – 22mm

Length:0.3 – 12m

Steel Grade:API 5L : GR B, X42, X46, X56, X60, X65, X70

ASTM A53: GR A, GR B, GR C

EN: S275, S275JR, S355JRH, S355J2H

GB: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555

Surface: Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement

Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.

Mill Test Certificate: EN 10204/3.1B

Payment Terms: T/T， L/C

Trade terms: FOB,CFR,CIF

Delivery Time: Within 30 days

Delivery way: sea transportation

Delivery Detail：Depends on your order quantity.

Packaging Detail: Packing in bundles or for the client’s requirement

Supply Ability: 500 Metric Ton/Metric Tons per Day
